7-22kW Home AC Charger. Perfect for residential use, delivering flexible and faster charging. Features a compact design, robust build, and smart connectivity for easy control. Safely powers up your EV overnight.

Specification

Product Series	HOME-Basic	HOME-Upgrade	Commercial
Charging interface	IEC 61851、GB/T 20234、GB/T 18487-2015, GB/T 20234-2015
Input Voltage Range	220VA ± 20% (1-phase) / 380VA ± 20%(3-phase)
Output Voltage Range	220VA ± 20% (1-phase) / 380VA ± 20%(3-phase)
Rated output current	16A/32A	16A/32A	16A/32A
Rated power	7kW/11KW/22KW	7kW/11KW/22KW	7kW/11KW/22KW
Working Frequency	45/65 Hz
Networking method	NA	WIFI	4G/WIFI/LAN
Bluetooth	NA	Yes	Optional
Control mode	Plug and Charge	APP control / RFID card	OCPP1.6 J (QR code / RFID)
IP grade	≥ IP55
Working Temperature	-40℃～ +60℃
Working Humidity	5%-95% Non-condensing
Special Protection	UV resistance
Working altitude	≤ 2000m
Operating instructions	On-screen display / Buzzer
Status indication	On-screen display /LED breathing light
Application Scenario	Outdoor indoor parking and charging
Weight	<7 kg		<8 kg
Dimension	238 mm x 95 mm x 348 mm

Why Choose Us


10 years manufacture experienceof new engery ev charger.	4000 square meters productionworkshop.	23+ industrial R&D and designteam,structure engineer team.

4 existing automatic andsemi-automatic production lines	60+ patent certificates.	20+test instruments

What are the advantages of our EV Charger?

01/ Complete Variety

AC and DC charging station equipment of national standard, European standard,American standard, and Japanese standard can be used.

02/ Wide Coverage

AC piles involving 3.5KW, 7KW, 11KW, 14KW, 22KW, 42KW, 84KW;DC piles: 7KW, 15KW, 20KW, 30kW, 40KW, 60KW to 480KW can be produced;AC-DC integrated charging stations can also be customized according to demand.

03/ Wide Practicability

Different pile types can be selected according to different environments anddifferent needs; for example AC piles can be wall-mounted, column-type, andfloor-mounted; DC piles can be selected from portable, wall-mounted, integrated.and split types.

04/ Intelligent

Through the intelligent cloud platform, online and offline real-time monitoring ofcharging pile data can be realized through intelligent management of the entirenetwork, intelligent control, intelligent maintenance, and comprehensiveextension of the integration of the Internet of Vehicles system.

05/ Convenience

Through the charging software, you can view the idle charging piles, filter thetypes of AC and DC piles, and guide users to charge, which is convenient and fast,and has complete functions. We can provide customized APp services.

FAQ

Q1: Can we ask you to print our logo into chargers? Can the color of the plug and wire be customized according to our requirements?

A: Yes. We support OEM/ODM production.

Q2: What is your quality control system?

A: Complete all incoming material inspection, process inspection, and final inspection; 30 test procedures will be done before the goods leave the factory, and charging test videos will be sent; products have CE, ROHS, FCC, UL, KC certification.

Q3: How do I select the type of charging stations?

A: If you need to charge your EV at anytime and anywhere, kindly please purchase the power adjustable portable charger, which can be placed in your car boot. If you have personal parking space,we suggest purchase a wallbox or floor mounted charging station.

Q4: What services can we provide?

A: 1. Free on-site touring and introduction of our factory.

2.We provide process design and validation for free.

3.We can guarantee on-time delivery of samples and goods.

4.Our products passed CE,ISO test. Accept third-party testing.

5.Close follow-up of all orders by special person and keep customers informed timely.
